Agile professional UAV platform under 25 kg
Lizard 800
Why choose Lizard 800?
Lizard platforms are built on a helicopter architecture designed for endurance, efficiency and mission reliability.
Unlike multirotors, this configuration excels in forward flight, range and payload capability.
Lizard platforms are built on a helicopter architecture designed for endurance, efficiency and mission reliability.
Unlike multirotors, this configuration excels in forward flight, range and payload capability.
Longer Endurance
Efficient cruise flight without excessive power drain
Higher Transit Speed
Reach remote areas faster than conventional multirotors
Extended Operational Range
Cover larger areas in a single mission
Payload Efficiency
Heavy loads without performance degradation
Wind & Weather Stability
Consistent control in challenging conditions
Key Capabilities & Features
Lightweight Platform
Under 25 kg total weight, enabling easy transport, simplified handling and rapid deployment without compromising operational capability.
Lightweight Platform
Rapid Deployment
Tool-less, quick assembly enables rapid deployment by a single operator, minimizing time-to-airborne when speed matters.
Rapid Deployment
Long-Range Operations
Supports long-range missions up to 100 km round-trip, enabling reliable reconnaissance and surveillance over wide areas.
Long-Range Operations
High Endurance
Up to 69 minutes of flight endurance, enabling extended missions with stable and controlled performance.
High Endurance
Technical Overview
Key Characteristics
Key Characteristics
Key Characteristics
Dimensions (L x W x H)
1530 x 300 x 580 mm
Dimensions (L x W x H)
1530 x 300 x 580 mm
Dimensions (L x W x H)
1530 x 300 x 580 mm
Rotor Diameter
1794 mm
Rotor Diameter
1794 mm
Rotor Diameter
1794 mm
Max. Take-off Weight
20 Kg
Max. Take-off Weight
20 Kg
Max. Take-off Weight
20 Kg
Weight (w\o batteries)
10.5 Kg
Weight (w\o batteries)
10.5 Kg
Weight (w\o batteries)
10.5 Kg
Payload Capacity
Up to 6 Kg
Payload Capacity
Up to 6 Kg
Payload Capacity
Up to 6 Kg
Endurance
70 min.
Endurance
70 min.
Endurance
70 min.
Optimal Cruise Speed
19 m/s (36.9 kn)
Optimal Cruise Speed
19 m/s (36.9 kn)
Optimal Cruise Speed
19 m/s (36.9 kn)
Max. Horizontal Speed
33 m/s (64 kn)
Max. Horizontal Speed
33 m/s (64 kn)
Max. Horizontal Speed
33 m/s (64 kn)
Max. Climb & Descent Speed
3 m/s
Max. Climb & Descent Speed
3 m/s
Max. Climb & Descent Speed
3 m/s
Deployment Area
6 m²
Deployment Area
6 m²
Deployment Area
6 m²
Deployment Time
<5 min.
Deployment Time
<5 min.
Deployment Time
<5 min.
Enviromental
Enviromental
Enviromental
Wind Resistance
20 m/s (38.9 kn)
Wind Resistance
20 m/s (38.9 kn)
Wind Resistance
20 m/s (38.9 kn)
Operating Temperature
-20° to +50° C (-4° to +122° F)
Operating Temperature
-20° to +50° C (-4° to +122° F)
Operating Temperature
-20° to +50° C (-4° to +122° F)
Max. Flight Altitude
4000 m
Max. Flight Altitude
4000 m
Max. Flight Altitude
4000 m
IP Rating
IP54
IP Rating
IP54
IP Rating
IP54
Applications for Lizard 800
Power Line / Pipeline Inspection
Carries LiDAR and RGB payloads in a single flight. Its swashplate rotor system ensures stability in every condition and environment.
Environmental Monitoring / Fire Surveillance
Supports hyperspectral and IR sensors for detecting fire hotspots and mapping CO2/CH4 emissions. Swappable batteries maximize up time.
Cave/Open-Pit & Stockpile Surveying
Carrying a LiDAR system, plus photogrammetry payload, LIZARD can survey entire pits without recharging thanks to its endurance.
Urban Law Enforcement & Public Safety
Low-noise operation and AI-powered tracking allow discreet surveillance and effective intervention in urban environments.
Power Line / Pipeline Inspection
Carries LiDAR and RGB payloads in a single flight. Its swashplate rotor system ensures stability in every condition and environment.
Environmental Monitoring / Fire Surveillance
Supports hyperspectral and IR sensors for detecting fire hotspots and mapping CO2/CH4 emissions. Swappable batteries maximize up time.
Cave/Open-Pit & Stockpile Surveying
Carrying a LiDAR system, plus photogrammetry payload, LIZARD can survey entire pits without recharging thanks to its endurance.
Urban Law Enforcement & Public Safety
Low-noise operation and AI-powered tracking allow discreet surveillance and effective intervention in urban environments.
Power Line / Pipeline Inspection
Carries LiDAR and RGB payloads in a single flight. Its swashplate rotor system ensures stability in every condition and environment.
Environmental Monitoring / Fire Surveillance
Supports hyperspectral and IR sensors for detecting fire hotspots and mapping CO2/CH4 emissions. Swappable batteries maximize up time.
Cave/Open-Pit & Stockpile Surveying
Carrying a LiDAR system, plus photogrammetry payload, LIZARD can survey entire pits without recharging thanks to its endurance.
Urban Law Enforcement & Public Safety
Low-noise operation and AI-powered tracking allow discreet surveillance and effective intervention in urban environments.
Engineered for demanding missions.
Built for missions where reliability defines success.
Engineered for demanding missions.
Built for missions where reliability defines success.
Engineered for demanding missions.
Built for missions where reliability defines success.
